实现游戏公告功能
实现功能：游戏管理里发布游戏公告，其它游戏玩家页面能够马上接受到游戏公告信息。
下面直接上代码案例，这里主要展示关键代码，底部有源码。
一、案例
1、pom.xml文件
主要是添加springBoot和webSocket相关jar包，和一些辅助工具jar包(注意我采用的是springBoot2.1.0版本
<?xml version="1.0" encoding="UTF-8"?><project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd"> <modelVersion>4.0.0</modelVersion> <groupId>com.jincou.websocket</groupId> <artifactId>websocketstudy</artifactId> <version>0.0.1-SNAPSHOT</version> <packaging>jar</packaging> <name>websocketstudy</name> <description>Demo project for Spring Boot</description> <parent> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-parent</artifactId> <version>2.1.0.BUILD-SNAPSHOT</version> <relativePath/> <!-- lookup parent from repository --> </parent> <properties> <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding> <project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding> <java.version>1.8</java.version> </properties> <dependencies> <!--springboot和websocket整合包--> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-websocket</artifactId> </dependency> <!--辅助包--> <dependency> <groupId>org.webjars</groupId> <artifactId>webjars-locator</artifactId> <version>0.32-1</version> </dependency> <dependency> <groupId>org.webjars</groupId> <artifactId>sockjs-client</artifactId> <version>1.0.2</version> </dependency> <dependency> <groupId>org.webjars</groupId> <artifactId>stomp-websocket</artifactId> <version>2.3.3</version> </dependency> <dependency> <groupId>org.webjars</groupId> <artifactId>bootstrap</artifactId> <version>3.3.7</version> </dependency> <dependency> <groupId>org.webjars</groupId> <artifactId>jquery</artifactId> <version>3.1.0</version> </dependency> <dependency> <groupId>org.projectlombok</groupId> <artifactId>lombok</artifactId> </dependency> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-test</artifactId> <scope>test</scope> </dependency> </dependencies> <build> <plugins> <plugin> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-maven-plugin</artifactId> </plugin> </plugins> </build> <repositories> <repository> <id>spring-snapshots</id> <name>Spring Snapshots</name> <url>https://repo.spring.io/snapshot</url> <snapshots> <enabled>true</enabled> </snapshots> </repository> <repository> <id>spring-milestones</id> <name>Spring Milestones</name> <url>https://repo.spring.io/milestone</url> <snapshots> <enabled>false</enabled> </snapshots> </repository> </repositories> <pluginRepositories> <pluginRepository> <id>spring-snapshots</id> <name>Spring Snapshots</name> <url>https://repo.spring.io/snapshot</url> <snapshots> <enabled>true</enabled> </snapshots> </pluginRepository> <pluginRepository> <id>spring-milestones</id> <name>Spring Milestones</name> <url>https://repo.spring.io/milestone</url> <snapshots> <enabled>false</enabled> </snapshots> </pluginRepository> </pluginRepositories></project>
pom.xml
2、WebSocketConfig
这个是websocket配置中心，配置一些核心配置。
import org.springframework.context.annotation.Configuration;import org.springframework.messaging.simp.config.MessageBrokerRegistry;import org.springframework.web.socket.config.annotation.EnableWebSocketMessageBroker;import org.springframework.web.socket.config.annotation.StompEndpointRegistry;import org.springframework.web.socket.config.annotation.WebSocketMessageBrokerConfigurer;@Configuration//注解用于开启使用STOMP协议来传输基于代理（MessageBroker）的消息，这时候控制器（controller）开始支持@MessageMapping,就像是使用@requestMapping一样。@EnableWebSocketMessageBrokerpublic class WebSocketConfig implements WebSocketMessageBrokerConfigurer { /**
* 注册端点，发布或者订阅消息的时候需要连接此端点
* setAllowedOrigins 非必须，*表示允许其他域进行连接
* withSockJS 表示开始sockejs支持 */
public void registerStompEndpoints(StompEndpointRegistry registry) {
registry.addEndpoint("/endpoint-websocket").setAllowedOrigins("*").withSockJS();
} /**
* 配置消息代理(中介)
* enableSimpleBroker 服务端推送给客户端的路径前缀
* setApplicationDestinationPrefixes 客户端发送数据给服务器端的一个前缀 */
@Override public void configureMessageBroker(MessageBrokerRegistry registry) {
registry.enableSimpleBroker("/topic");
registry.setApplicationDestinationPrefixes("/app");
}
}
3、GameInfoController
管理员发布公告消息对应的接口
/*
*模拟游戏公告 */@Controllerpublic class GameInfoController { //@MessageMapping和@RequestMapping功能类似，用于设置URL映射地址，浏览器向服务器发起请求，需要通过该地址。 //如果服务器接受到了消息，就会对订阅了@SendTo括号中的地址传送消息。
@MessageMapping("/gonggao/chat") @SendTo("/topic/game_chat") public OutMessage gameInfo(InMessage message){ return new OutMessage(message.getContent());
}
}
4、管理员页面和用户页面
admin页面和user页面唯一的区别就是管理员多一个发送公告的权限，其它都一样，user1和user2完全一样。
（1）admin.html
admin.html
（2）user1.html
user1.html
(3）user2.html
user2.html
5.app.js
这个是客户端连接websocket的核心，通过html的点击事件来完成。
var stompClient = null;//这个方法仅仅是用来改变样式，不是核心function setConnected(connected) {
$("#connect").prop("disabled", connected);
$("#disconnect").prop("disabled", !connected); if (connected) {
$("#conversation").show();
} else {
$("#conversation").hide();
}
$("#notice").html("");
}//1、建立连接（先连接服务端配置文件中的基站，建立连接，然后订阅服务器目录消息function connect() { //1、连接SockJS的endpoint是“endpoint-websocket”，与后台代码中注册的endpoint要一样。
var socket = new SockJS('/endpoint-websocket'); //2、用stom进行包装，规范协议
stompClient = Stomp.over(socket);
stompClient.connect({}, function (frame) { //3、建立通讯
setConnected(true);
console.log('Connected: ' + frame); //4、通过stompClient.subscribe（）订阅服务器的目标是'/topic/game_chat'发送过来的地址，与@SendTo中的地址对应。
stompClient.subscribe('/topic/game_chat', function (result) {
console.info(result)
showContent(JSON.parse(result.body));
});
});
}//2、关闭连接function disconnect() { if (stompClient !== null) {
stompClient.disconnect();
}
setConnected(false);
console.log("Disconnected");
}//3、游戏管理员发送公告信息（这个也是游戏用户所没有功能，其它都一样）function sendName() { //1、通过stompClient.send 向/app/gonggao/chat 目标 发送消息,这个是在控制器的@messageMapping 中定义的。(/app为前缀，配置里配置）
stompClient.send("/app/gonggao/chat", {}, JSON.stringify({'content': $("#content").val()}));
}//4、订阅的消息显示在客户端指定位置function showContent(body) {
$("#notice").append("<tr><td>" + body.content + "</td> <td>"+new Date(body.time).toLocaleString()+"</td></tr>");
}
$(function () {
$("form").on('submit', function (e) {
e.preventDefault();
});
$( "#connect" ).click(function() { connect(); });
$( "#disconnect" ).click(function() { disconnect(); });
$( "#send" ).click(function() { sendName(); });
});
6、查看运行结果
7、小总结
首先很明显看的出，websocket最大的优点，就是可以服务端主动向客户端发送消息，而此前http只能是客户端向服务端发送请求。
gitHub源码：https://github.com/yudiandemingzi/websocket
原文出处：https://www.cnblogs.com/qdhxhz/p/9438954.html
