Spring Security 架构与源码分析

标签：

Java 职场生活

Spring Security 主要实现了Authentication（认证，解决who are you? ）和 Access Control（访问控制，也就是what are you allowed to do？，也称为Authorization）。Spring Security在架构上将认证与授权分离，并提供了扩展点。

核心对象

主要代码在spring-security-core包下面。要了解Spring Security，需要先关注里面的核心对象。

SecurityContextHolder, SecurityContext 和 Authentication

SecurityContextHolder 是 SecurityContext的存放容器，默认使用ThreadLocal 存储，意味SecurityContext在相同线程中的方法都可用。
SecurityContext主要是存储应用的principal信息，在Spring Security中用Authentication 来表示。

获取principal：

Object principal = SecurityContextHolder.getContext().getAuthentication().getPrincipal();if (principal instanceof UserDetails) {
String username = ((UserDetails)principal).getUsername();
} else {
String username = principal.toString();
}

在Spring Security中，可以看一下Authentication定义：

public interface Authentication extends Principal, Serializable {

    Collection<? extends GrantedAuthority> getAuthorities();    /**     * 通常是密码     */
    Object getCredentials();    /**     * Stores additional details about the authentication request. These might be an IP     * address, certificate serial number etc.     */
    Object getDetails();    /**     * 用来标识是否已认证，如果使用用户名和密码登录,通常是用户名      */
    Object getPrincipal();    /**     * 是否已认证     */
    boolean isAuthenticated();    void setAuthenticated(boolean isAuthenticated) throws IllegalArgumentException;
}

在实际应用中，通常使用UsernamePasswordAuthenticationToken：

public abstract class AbstractAuthenticationToken implements Authentication,        CredentialsContainer {
        }public class UsernamePasswordAuthenticationToken extends AbstractAuthenticationToken {
}

一个常见的认证过程通常是这样的，创建一个UsernamePasswordAuthenticationToken，然后交给authenticationManager认证（后面详细说明），认证通过则通过SecurityContextHolder存放Authentication信息。

 UsernamePasswordAuthenticationToken authenticationToken =            new UsernamePasswordAuthenticationToken(loginVM.getUsername(), loginVM.getPassword());

Authentication authentication = this.authenticationManager.authenticate(authenticationToken);
SecurityContextHolder.getContext().setAuthentication(authentication);

UserDetails与UserDetailsService

UserDetails 是Spring Security里的一个关键接口，他用来表示一个principal。

public interface UserDetails extends Serializable {    /**     * 用户的授权信息，可以理解为角色     */
    Collection<? extends GrantedAuthority> getAuthorities();    /**     * 用户密码     *     * @return the password     */
    String getPassword();    /**     * 用户名      *   */
    String getUsername();    boolean isAccountNonExpired();    boolean isAccountNonLocked();    boolean isCredentialsNonExpired();    boolean isEnabled();
}

UserDetails提供了认证所需的必要信息，在实际使用里，可以自己实现UserDetails，并增加额外的信息，比如email、mobile等信息。

在Authentication中的principal通常是用户名，我们可以通过UserDetailsService来通过principal获取UserDetails：

public interface UserDetailsService {    UserDetails loadUserByUsername(String username) throws UsernameNotFoundException;
}

GrantedAuthority

在UserDetails里说了，GrantedAuthority可以理解为角色，例如 ROLE_ADMINISTRATOR or ROLE_HR_SUPERVISOR。

小结

SecurityContextHolder, 用来访问 SecurityContext.
SecurityContext, 用来存储Authentication .
Authentication, 代表凭证.
GrantedAuthority, 代表权限.
UserDetails, 用户信息.
UserDetailsService,获取用户信息.

Authentication认证

AuthenticationManager

实现认证主要是通过AuthenticationManager接口，它只包含了一个方法：

public interface AuthenticationManager {  Authentication authenticate(Authentication authentication)
    throws AuthenticationException;
}

authenticate()方法主要做三件事：

如果验证通过，返回Authentication（通常带上authenticated=true）。
认证失败抛出AuthenticationException
如果无法确定，则返回null

AuthenticationException是运行时异常,它通常由应用程序按通用方式处理，用户代码通常不用特意被捕获和处理这个异常。

AuthenticationManager的默认实现是ProviderManager，它委托一组AuthenticationProvider实例来实现认证。
AuthenticationProvider和AuthenticationManager类似，都包含authenticate，但它有一个额外的方法supports，以允许查询调用方是否支持给定Authentication类型：

public interface AuthenticationProvider {    Authentication authenticate(Authentication authentication)
            throws AuthenticationException;    boolean supports(Class<?> authentication);
}

ProviderManager包含一组AuthenticationProvider，执行authenticate时，遍历Providers，然后调用supports，如果支持，则执行遍历当前provider的authenticate方法，如果一个provider认证成功，则break。

public Authentication authenticate(Authentication authentication)
            throws AuthenticationException {
        Class<? extends Authentication> toTest = authentication.getClass();
        AuthenticationException lastException = null;
        Authentication result = null;        boolean debug = logger.isDebugEnabled();        for (AuthenticationProvider provider : getProviders()) {            if (!provider.supports(toTest)) {                continue;
            }            if (debug) {
                logger.debug("Authentication attempt using "
                        + provider.getClass().getName());
            }            try {
                result = provider.authenticate(authentication);                if (result != null) {                    copyDetails(authentication, result);                    break;
                }
            }            catch (AccountStatusException e) {                prepareException(e, authentication);                // SEC-546: Avoid polling additional providers if auth failure is due to
                // invalid account status
                throw e;
            }            catch (InternalAuthenticationServiceException e) {                prepareException(e, authentication);                throw e;
            }            catch (AuthenticationException e) {
                lastException = e;
            }
        }        if (result == null && parent != null) {            // Allow the parent to try.
            try {
                result = parent.authenticate(authentication);
            }            catch (ProviderNotFoundException e) {                // ignore as we will throw below if no other exception occurred prior to
                // calling parent and the parent
                // may throw ProviderNotFound even though a provider in the child already
                // handled the request
            }            catch (AuthenticationException e) {
                lastException = e;
            }
        }        if (result != null) {            if (eraseCredentialsAfterAuthentication
                    && (result instanceof CredentialsContainer)) {                // Authentication is complete. Remove credentials and other secret data
                // from authentication
                ((CredentialsContainer) result).eraseCredentials();
            }

            eventPublisher.publishAuthenticationSuccess(result);            return result;
        }        // Parent was null, or didn't authenticate (or throw an exception).

        if (lastException == null) {
            lastException = new ProviderNotFoundException(messages.getMessage(                    "ProviderManager.providerNotFound",                    new Object[] { toTest.getName() },                    "No AuthenticationProvider found for {0}"));
        }        prepareException(lastException, authentication);        throw lastException;
    }

从上面的代码可以看出， ProviderManager有一个可选parent，如果parent不为空，则调用parent.authenticate(authentication)

AuthenticationProvider

AuthenticationProvider有多种实现，大家最关注的通常是DaoAuthenticationProvider，继承于AbstractUserDetailsAuthenticationProvider，核心是通过UserDetails来实现认证,DaoAuthenticationProvider默认会自动加载，不用手动配。

先来看AbstractUserDetailsAuthenticationProvider，看最核心的authenticate：

public Authentication authenticate(Authentication authentication)
            throws AuthenticationException {        // 必须是UsernamePasswordAuthenticationToken
        Assert.isInstanceOf(UsernamePasswordAuthenticationToken.class, authentication,
                messages.getMessage(                        "AbstractUserDetailsAuthenticationProvider.onlySupports",                        "Only UsernamePasswordAuthenticationToken is supported"));        //  获取用户名
        String username = (authentication.getPrincipal() == null) ? "NONE_PROVIDED"
                : authentication.getName();        boolean cacheWasUsed = true;        // 从缓存获取
        UserDetails user = this.userCache.getUserFromCache(username);        if (user == null) {
            cacheWasUsed = false;            try {               // retrieveUser 抽象方法，获取用户
                user = retrieveUser(username,
                        (UsernamePasswordAuthenticationToken) authentication);
            }            catch (UsernameNotFoundException notFound) {
                logger.debug("User '" + username + "' not found");                if (hideUserNotFoundExceptions) {                    throw new BadCredentialsException(messages.getMessage(                            "AbstractUserDetailsAuthenticationProvider.badCredentials",                            "Bad credentials"));
                }                else {                    throw notFound;
                }
            }

            Assert.notNull(user,                    "retrieveUser returned null - a violation of the interface contract");
        }        try {            // 预先检查，DefaultPreAuthenticationChecks，检查用户是否被lock或者账号是否可用
            preAuthenticationChecks.check(user);
            // 抽象方法，自定义检验
            additionalAuthenticationChecks(user,
                    (UsernamePasswordAuthenticationToken) authentication);
        }        catch (AuthenticationException exception) {            if (cacheWasUsed) {                // There was a problem, so try again after checking
                // we're using latest data (i.e. not from the cache)
                cacheWasUsed = false;
                user = retrieveUser(username,
                        (UsernamePasswordAuthenticationToken) authentication);
                preAuthenticationChecks.check(user);                additionalAuthenticationChecks(user,
                        (UsernamePasswordAuthenticationToken) authentication);
            }            else {                throw exception;
            }
        }
        // 后置检查 DefaultPostAuthenticationChecks，检查isCredentialsNonExpired
        postAuthenticationChecks.check(user);        if (!cacheWasUsed) {            this.userCache.putUserInCache(user);
        }

        Object principalToReturn = user;        if (forcePrincipalAsString) {
            principalToReturn = user.getUsername();
        }
        return createSuccessAuthentication(principalToReturn, authentication, user);
    }

上面的检验主要基于UserDetails实现，其中获取用户和检验逻辑由具体的类去实现，默认实现是DaoAuthenticationProvider，这个类的核心是让开发者提供UserDetailsService来获取UserDetails以及 PasswordEncoder来检验密码是否有效：

private UserDetailsService userDetailsService;private PasswordEncoder passwordEncoder;

看具体的实现，retrieveUser,直接调用userDetailsService获取用户：

protected final UserDetails retrieveUser(String username,
            UsernamePasswordAuthenticationToken authentication)
            throws AuthenticationException {
        UserDetails loadedUser;        try {
            loadedUser = this.getUserDetailsService().loadUserByUsername(username);
        }        catch (UsernameNotFoundException notFound) {            if (authentication.getCredentials() != null) {
                String presentedPassword = authentication.getCredentials().toString();
                passwordEncoder.isPasswordValid(userNotFoundEncodedPassword,
                        presentedPassword, null);
            }            throw notFound;
        }        catch (Exception repositoryProblem) {            throw new InternalAuthenticationServiceException(
                    repositoryProblem.getMessage(), repositoryProblem);
        }        if (loadedUser == null) {            throw new InternalAuthenticationServiceException(                    "UserDetailsService returned null, which is an interface contract violation");
        }        return loadedUser;
    }

再来看验证：

protected void additionalAuthenticationChecks(UserDetails userDetails,
            UsernamePasswordAuthenticationToken authentication)
            throws AuthenticationException {
        Object salt = null;        if (this.saltSource != null) {
            salt = this.saltSource.getSalt(userDetails);
        }        if (authentication.getCredentials() == null) {
            logger.debug("Authentication failed: no credentials provided");            throw new BadCredentialsException(messages.getMessage(                    "AbstractUserDetailsAuthenticationProvider.badCredentials",                    "Bad credentials"));
        }        // 获取用户密码
        String presentedPassword = authentication.getCredentials().toString();        // 比较passwordEncoder后的密码是否和userdetails的密码一致
        if (!passwordEncoder.isPasswordValid(userDetails.getPassword(),
                presentedPassword, salt)) {
            logger.debug("Authentication failed: password does not match stored value");            throw new BadCredentialsException(messages.getMessage(                    "AbstractUserDetailsAuthenticationProvider.badCredentials",                    "Bad credentials"));
        }
    }

小结：要自定义认证，使用DaoAuthenticationProvider，只需要为其提供PasswordEncoder和UserDetailsService就可以了。

定制 Authentication Managers

Spring Security提供了一个Builder类AuthenticationManagerBuilder，借助它可以快速实现自定义认证。

看官方源码说明：

SecurityBuilder used to create an AuthenticationManager . Allows for easily building in memory authentication, LDAP authentication, JDBC based authentication, adding UserDetailsService , and adding AuthenticationProvider's.

AuthenticationManagerBuilder可以用来Build一个AuthenticationManager，可以创建基于内存的认证、LDAP认证、 JDBC认证，以及添加UserDetailsService和AuthenticationProvider。

简单使用：

@Configuration@EnableWebSecurity@EnableGlobalMethodSecurity(prePostEnabled = true, securedEnabled = true)public class ApplicationSecurity extends WebSecurityConfigurerAdapter {  public SecurityConfiguration(AuthenticationManagerBuilder authenticationManagerBuilder, UserDetailsService userDetailsService,TokenProvider tokenProvider,CorsFilter corsFilter, SecurityProblemSupport problemSupport) {        this.authenticationManagerBuilder = authenticationManagerBuilder;        this.userDetailsService = userDetailsService;        this.tokenProvider = tokenProvider;        this.corsFilter = corsFilter;        this.problemSupport = problemSupport;
    }    @PostConstruct
    public void init() {        try {
            authenticationManagerBuilder
                .userDetailsService(userDetailsService)
                .passwordEncoder(passwordEncoder());
        } catch (Exception e) {            throw new BeanInitializationException("Security configuration failed", e);
        }
    }   @Override
    protected void configure(HttpSecurity http) throws Exception {
        http
            .addFilterBefore(corsFilter, UsernamePasswordAuthenticationFilter.class)
            .exceptionHandling()
            .authenticationEntryPoint(problemSupport)
            .accessDeniedHandler(problemSupport)
        .and()
            .csrf()
            .disable()
            .headers()
            .frameOptions()
            .disable()
        .and()
            .sessionManagement()
            .sessionCreationPolicy(SessionCreationPolicy.STATELESS)
        .and()
            .authorizeRequests()
            .antMatchers("/api/register").permitAll()
            .antMatchers("/api/activate").permitAll()
            .antMatchers("/api/authenticate").permitAll()
            .antMatchers("/api/account/reset-password/init").permitAll()
            .antMatchers("/api/account/reset-password/finish").permitAll()
            .antMatchers("/api/profile-info").permitAll()
            .antMatchers("/api/**").authenticated()
            .antMatchers("/management/health").permitAll()
            .antMatchers("/management/**").hasAuthority(AuthoritiesConstants.ADMIN)
            .antMatchers("/v2/api-docs/**").permitAll()
            .antMatchers("/swagger-resources/configuration/ui").permitAll()
            .antMatchers("/swagger-ui/index.html").hasAuthority(AuthoritiesConstants.ADMIN)
        .and()
            .apply(securityConfigurerAdapter());

    }
}

授权与访问控制

一旦认证成功，我们可以继续进行授权，授权是通过AccessDecisionManager来实现的。框架有三种实现，默认是AffirmativeBased，通过AccessDecisionVoter决策，有点像ProviderManager委托给AuthenticationProviders来认证。

public void decide(Authentication authentication, Object object,
            Collection<ConfigAttribute> configAttributes) throws AccessDeniedException {        int deny = 0;        // 遍历DecisionVoter
        for (AccessDecisionVoter voter : getDecisionVoters()) {            // 投票
            int result = voter.vote(authentication, object, configAttributes);            if (logger.isDebugEnabled()) {
                logger.debug("Voter: " + voter + ", returned: " + result);
            }            switch (result) {            case AccessDecisionVoter.ACCESS_GRANTED:                return;            case AccessDecisionVoter.ACCESS_DENIED:
                deny++;                break;            default:                break;
            }
        }
        // 一票否决
        if (deny > 0) {            throw new AccessDeniedException(messages.getMessage(                    "AbstractAccessDecisionManager.accessDenied", "Access is denied"));
        }        // To get this far, every AccessDecisionVoter abstained
        checkAllowIfAllAbstainDecisions();
    }

来看AccessDecisionVoter：

boolean supports(ConfigAttribute attribute);boolean supports(Class<?> clazz);int vote(Authentication authentication, S object,
        Collection<ConfigAttribute> attributes);

object是用户要访问的资源，ConfigAttribute则是访问object要满足的条件，通常payload是字符串，比如ROLE_ADMIN 。所以我们来看下RoleVoter的实现，其核心就是从authentication提取出GrantedAuthority，然后和ConfigAttribute比较是否满足条件。

public boolean supports(ConfigAttribute attribute) {        if ((attribute.getAttribute() != null)
                && attribute.getAttribute().startsWith(getRolePrefix())) {            return true;
        }        else {            return false;
        }
    }
public boolean supports(Class<?> clazz) {        return true;
    }public int vote(Authentication authentication, Object object,
            Collection<ConfigAttribute> attributes) {        if(authentication == null) {            return ACCESS_DENIED;
        }        int result = ACCESS_ABSTAIN;
        // 获取GrantedAuthority信息
        Collection<? extends GrantedAuthority> authorities = extractAuthorities(authentication);        for (ConfigAttribute attribute : attributes) {            if (this.supports(attribute)) {                // 默认拒绝访问
                result = ACCESS_DENIED;                // Attempt to find a matching granted authority
                for (GrantedAuthority authority : authorities) {                     // 判断是否有匹配的 authority
                    if (attribute.getAttribute().equals(authority.getAuthority())) {                        // 可访问
                        return ACCESS_GRANTED;
                    }
                }
            }
        }        return result;
    }

这里要疑问，ConfigAttribute哪来的？其实就是上面ApplicationSecurity的configure里的。

web security 如何实现

Web层中的Spring Security（用于UI和HTTP后端）基于Servlet Filters，下图显示了单个HTTP请求的处理程序的典型分层。

Spring Security通过FilterChainProxy作为单一的Filter注册到web层，Proxy内部的Filter。

FilterChainProxy相当于一个filter的容器，通过VirtualFilterChain来依次调用各个内部filter

public void doFilter(ServletRequest request, ServletResponse response,
            FilterChain chain) throws IOException, ServletException {        boolean clearContext = request.getAttribute(FILTER_APPLIED) == null;        if (clearContext) {            try {
                request.setAttribute(FILTER_APPLIED, Boolean.TRUE);                doFilterInternal(request, response, chain);
            }            finally {
                SecurityContextHolder.clearContext();
                request.removeAttribute(FILTER_APPLIED);
            }
        }        else {            doFilterInternal(request, response, chain);
        }
    }    private void doFilterInternal(ServletRequest request, ServletResponse response,
            FilterChain chain) throws IOException, ServletException {

        FirewalledRequest fwRequest = firewall
                .getFirewalledRequest((HttpServletRequest) request);
        HttpServletResponse fwResponse = firewall
                .getFirewalledResponse((HttpServletResponse) response);

        List<Filter> filters = getFilters(fwRequest);        if (filters == null || filters.size() == 0) {            if (logger.isDebugEnabled()) {
                logger.debug(UrlUtils.buildRequestUrl(fwRequest)
                        + (filters == null ? " has no matching filters"
                                : " has an empty filter list"));
            }

            fwRequest.reset();

            chain.doFilter(fwRequest, fwResponse);            return;
        }

        VirtualFilterChain vfc = new VirtualFilterChain(fwRequest, chain, filters);
        vfc.doFilter(fwRequest, fwResponse);
    }
    private static class VirtualFilterChain implements FilterChain {        private final FilterChain originalChain;        private final List<Filter> additionalFilters;        private final FirewalledRequest firewalledRequest;        private final int size;        private int currentPosition = 0;        private VirtualFilterChain(FirewalledRequest firewalledRequest,
                FilterChain chain, List<Filter> additionalFilters) {            this.originalChain = chain;            this.additionalFilters = additionalFilters;            this.size = additionalFilters.size();            this.firewalledRequest = firewalledRequest;
        }        public void doFilter(ServletRequest request, ServletResponse response)
                throws IOException, ServletException {            if (currentPosition == size) {                if (logger.isDebugEnabled()) {
                    logger.debug(UrlUtils.buildRequestUrl(firewalledRequest)
                            + " reached end of additional filter chain; proceeding with original chain");
                }                // Deactivate path stripping as we exit the security filter chain
                this.firewalledRequest.reset();

                originalChain.doFilter(request, response);
            }            else {
                currentPosition++;

                Filter nextFilter = additionalFilters.get(currentPosition - 1);                if (logger.isDebugEnabled()) {
                    logger.debug(UrlUtils.buildRequestUrl(firewalledRequest)
                            + " at position " + currentPosition + " of " + size
                            + " in additional filter chain; firing Filter: '"
                            + nextFilter.getClass().getSimpleName() + "'");
                }

                nextFilter.doFilter(request, response, this);
            }
        }
    }

参考

https://spring.io/guides/topicals/spring-security-architecture/
https://docs.spring.io/spring-security/site/docs/5.0.5.RELEASE/reference/htmlsingle/#overall-architecture
作者：Jadepeng
出处：jqpeng的技术记事本--http://www.cnblogs.com/xiaoqi
您的支持是对博主最大的鼓励，感谢您的认真阅读。
本文版权归作者所有，欢迎转载，但未经作者同意必须保留此段声明，且在文章页面明显位置给出原文连接，否则保留追究法律责任的权利。

点击查看更多内容
