gitbook 入门教程之超高颜值的思维导图simple-mind-map插件

标签：
Node.js webpack 正则表达式


在 markdown 中生成并导出思维导图的 Gitbook 插件

屏幕截图

{% simplemindmap %}

```markdown
- simplemindmap
  - config book.json
    - plugins
      - others
      - simple-mind-map
    - pluginsConfig
      - others
      - simple-mind-map
        - type
        - preset
        - linkShape
        - autoFit
        - style
  - custom file.md
    - markdown
      - type
      - preset
      - linkShape
      - autoFit
      - style
    - txtmap
    - json
    - mindmup
```

{% endsimplemindmap %}


用法

步骤＃1-更新 book.json 文件

在您的 gitbook 的 book.json 文件中,将 simple-mind-map 添加到 plugins 列表中.

这是最简单的示例：

{
    "plugins": ["simple-mind-map"]
}

此外,受支持的配置选项如下:

"gitbook": {
    "properties": {
        "type": {
            "type": "string",
            "title": "Markdown or MindMup or Txtmap or Pandoc",
            "required": false,
            "default": "markdown"
        },
        "preset": {
            "type": "string",
            "title": "colorful or default",
            "required": false,
            "default": "colorful"
        },
        "linkShape": {
            "type": "string",
            "title": "diagonal or bracket",
            "required": false,
            "default": "diagonal"
        },
        "autoFit": {
            "type": "boolean",
            "title": "true or false",
            "required": false,
            "default": true
        },
        "style": {
            "type": "object",
            "title": "custom style",
            "required": false
        }
    }
}

步骤＃2- 使用 markdown 语法

simplemindmap 插件支持 type,preset,linkShape,autoFit 和 style 等选项生成思维导图.

这是在 markdown 文件中基本使用语法:

{% simplemindmap %}
```
simple mind map
```
{% endsimplemindmap %}

下面有一些基本示例:

  • markdown

默认配置生成 markdown 版本的思维导图

{% simplemindmap %}

```markdown
- simplemindmap
  - config book.json
    - plugins
      - others
      - simple-mind-map
    - pluginsConfig
      - others
      - simple-mind-map
        - type
        - preset
        - linkShape
        - autoFit
        - style
  - custom file.md
    - markdown
      - type
      - preset
      - linkShape
      - autoFit
      - style
    - txtmap
    - json
    - mindmup
```

{% endsimplemindmap %}


  • txtmap

指定语言类型 type 生成 txtmap 版本的思维导图

{% simplemindmap type="txtmap" %}
```txtmap
some
  example
    content
  for
  you
    to
    see
      the
    file
      structure
```
{% endsimplemindmap %}


  • json

指定预设值 preset 和自定义样式 style 生成 json 版本的思维导图

{% simplemindmap type="json",preset="default",style={"height":"2000px"} %}
```json
{
 "name": "flare",
 "children": [
  {
   "name": "analytics",
   "children": [
    {
     "name": "cluster",
     "children": [
      {"name": "AgglomerativeCluster", "size": 3938},
      {"name": "CommunityStructure", "size": 3812},
      {"name": "HierarchicalCluster", "size": 6714},
      {"name": "MergeEdge", "size": 743}
     ]
    },
    {
     "name": "graph",
     "children": [
      {"name": "BetweennessCentrality", "size": 3534},
      {"name": "LinkDistance", "size": 5731},
      {"name": "MaxFlowMinCut", "size": 7840},
      {"name": "ShortestPaths", "size": 5914},
      {"name": "SpanningTree", "size": 3416}
     ]
    },
    {
     "name": "optimization",
     "children": [
      {"name": "AspectRatioBanker", "size": 7074}
     ]
    }
   ]
  },
  {
   "name": "animate",
   "children": [
    {"name": "Easing", "size": 17010},
    {"name": "FunctionSequence", "size": 5842},
    {
     "name": "interpolate",
     "children": [
      {"name": "ArrayInterpolator", "size": 1983},
      {"name": "ColorInterpolator", "size": 2047},
      {"name": "DateInterpolator", "size": 1375},
      {"name": "Interpolator", "size": 8746},
      {"name": "MatrixInterpolator", "size": 2202},
      {"name": "NumberInterpolator", "size": 1382},
      {"name": "ObjectInterpolator", "size": 1629},
      {"name": "PointInterpolator", "size": 1675},
      {"name": "RectangleInterpolator", "size": 2042}
     ]
    },
    {"name": "ISchedulable", "size": 1041},
    {"name": "Parallel", "size": 5176},
    {"name": "Pause", "size": 449},
    {"name": "Scheduler", "size": 5593},
    {"name": "Sequence", "size": 5534},
    {"name": "Transition", "size": 9201},
    {"name": "Transitioner", "size": 19975},
    {"name": "TransitionEvent", "size": 1116},
    {"name": "Tween", "size": 6006}
   ]
  },
  {
   "name": "data",
   "children": [
    {
     "name": "converters",
     "children": [
      {"name": "Converters", "size": 721},
      {"name": "DelimitedTextConverter", "size": 4294},
      {"name": "GraphMLConverter", "size": 9800},
      {"name": "IDataConverter", "size": 1314},
      {"name": "JSONConverter", "size": 2220}
     ]
    },
    {"name": "DataField", "size": 1759},
    {"name": "DataSchema", "size": 2165},
    {"name": "DataSet", "size": 586},
    {"name": "DataSource", "size": 3331},
    {"name": "DataTable", "size": 772},
    {"name": "DataUtil", "size": 3322}
   ]
  },
  {
   "name": "display",
   "children": [
    {"name": "DirtySprite", "size": 8833},
    {"name": "LineSprite", "size": 1732},
    {"name": "RectSprite", "size": 3623},
    {"name": "TextSprite", "size": 10066}
   ]
  },
  {
   "name": "flex",
   "children": [
    {"name": "FlareVis", "size": 4116}
   ]
  },
  {
   "name": "physics",
   "children": [
    {"name": "DragForce", "size": 1082},
    {"name": "GravityForce", "size": 1336},
    {"name": "IForce", "size": 319},
    {"name": "NBodyForce", "size": 10498},
    {"name": "Particle", "size": 2822},
    {"name": "Simulation", "size": 9983},
    {"name": "Spring", "size": 2213},
    {"name": "SpringForce", "size": 1681}
   ]
  },
  {
   "name": "query",
   "children": [
    {"name": "AggregateExpression", "size": 1616},
    {"name": "And", "size": 1027},
    {"name": "Arithmetic", "size": 3891},
    {"name": "Average", "size": 891},
    {"name": "BinaryExpression", "size": 2893},
    {"name": "Comparison", "size": 5103},
    {"name": "CompositeExpression", "size": 3677},
    {"name": "Count", "size": 781},
    {"name": "DateUtil", "size": 4141},
    {"name": "Distinct", "size": 933},
    {"name": "Expression", "size": 5130},
    {"name": "ExpressionIterator", "size": 3617},
    {"name": "Fn", "size": 3240},
    {"name": "If", "size": 2732},
    {"name": "IsA", "size": 2039},
    {"name": "Literal", "size": 1214},
    {"name": "Match", "size": 3748},
    {"name": "Maximum", "size": 843},
    {
     "name": "methods",
     "children": [
      {"name": "add", "size": 593},
      {"name": "and", "size": 330},
      {"name": "average", "size": 287},
      {"name": "count", "size": 277},
      {"name": "distinct", "size": 292},
      {"name": "div", "size": 595},
      {"name": "eq", "size": 594},
      {"name": "fn", "size": 460},
      {"name": "gt", "size": 603},
      {"name": "gte", "size": 625},
      {"name": "iff", "size": 748},
      {"name": "isa", "size": 461},
      {"name": "lt", "size": 597},
      {"name": "lte", "size": 619},
      {"name": "max", "size": 283},
      {"name": "min", "size": 283},
      {"name": "mod", "size": 591},
      {"name": "mul", "size": 603},
      {"name": "neq", "size": 599},
      {"name": "not", "size": 386},
      {"name": "or", "size": 323},
      {"name": "orderby", "size": 307},
      {"name": "range", "size": 772},
      {"name": "select", "size": 296},
      {"name": "stddev", "size": 363},
      {"name": "sub", "size": 600},
      {"name": "sum", "size": 280},
      {"name": "update", "size": 307},
      {"name": "variance", "size": 335},
      {"name": "where", "size": 299},
      {"name": "xor", "size": 354},
      {"name": "_", "size": 264}
     ]
    },
    {"name": "Minimum", "size": 843},
    {"name": "Not", "size": 1554},
    {"name": "Or", "size": 970},
    {"name": "Query", "size": 13896},
    {"name": "Range", "size": 1594},
    {"name": "StringUtil", "size": 4130},
    {"name": "Sum", "size": 791},
    {"name": "Variable", "size": 1124},
    {"name": "Variance", "size": 1876},
    {"name": "Xor", "size": 1101}
   ]
  },
  {
   "name": "scale",
   "children": [
    {"name": "IScaleMap", "size": 2105},
    {"name": "LinearScale", "size": 1316},
    {"name": "LogScale", "size": 3151},
    {"name": "OrdinalScale", "size": 3770},
    {"name": "QuantileScale", "size": 2435},
    {"name": "QuantitativeScale", "size": 4839},
    {"name": "RootScale", "size": 1756},
    {"name": "Scale", "size": 4268},
    {"name": "ScaleType", "size": 1821},
    {"name": "TimeScale", "size": 5833}
   ]
  },
  {
   "name": "util",
   "children": [
    {"name": "Arrays", "size": 8258},
    {"name": "Colors", "size": 10001},
    {"name": "Dates", "size": 8217},
    {"name": "Displays", "size": 12555},
    {"name": "Filter", "size": 2324},
    {"name": "Geometry", "size": 10993},
    {
     "name": "heap",
     "children": [
      {"name": "FibonacciHeap", "size": 9354},
      {"name": "HeapNode", "size": 1233}
     ]
    },
    {"name": "IEvaluable", "size": 335},
    {"name": "IPredicate", "size": 383},
    {"name": "IValueProxy", "size": 874},
    {
     "name": "math",
     "children": [
      {"name": "DenseMatrix", "size": 3165},
      {"name": "IMatrix", "size": 2815},
      {"name": "SparseMatrix", "size": 3366}
     ]
    },
    {"name": "Maths", "size": 17705},
    {"name": "Orientation", "size": 1486},
    {
     "name": "palette",
     "children": [
      {"name": "ColorPalette", "size": 6367},
      {"name": "Palette", "size": 1229},
      {"name": "ShapePalette", "size": 2059},
      {"name": "SizePalette", "size": 2291}
     ]
    },
    {"name": "Property", "size": 5559},
    {"name": "Shapes", "size": 19118},
    {"name": "Sort", "size": 6887},
    {"name": "Stats", "size": 6557},
    {"name": "Strings", "size": 22026}
   ]
  },
  {
   "name": "vis",
   "children": [
    {
     "name": "axis",
     "children": [
      {"name": "Axes", "size": 1302},
      {"name": "Axis", "size": 24593},
      {"name": "AxisGridLine", "size": 652},
      {"name": "AxisLabel", "size": 636},
      {"name": "CartesianAxes", "size": 6703}
     ]
    },
    {
     "name": "controls",
     "children": [
      {"name": "AnchorControl", "size": 2138},
      {"name": "ClickControl", "size": 3824},
      {"name": "Control", "size": 1353},
      {"name": "ControlList", "size": 4665},
      {"name": "DragControl", "size": 2649},
      {"name": "ExpandControl", "size": 2832},
      {"name": "HoverControl", "size": 4896},
      {"name": "IControl", "size": 763},
      {"name": "PanZoomControl", "size": 5222},
      {"name": "SelectionControl", "size": 7862},
      {"name": "TooltipControl", "size": 8435}
     ]
    },
    {
     "name": "data",
     "children": [
      {"name": "Data", "size": 20544},
      {"name": "DataList", "size": 19788},
      {"name": "DataSprite", "size": 10349},
      {"name": "EdgeSprite", "size": 3301},
      {"name": "NodeSprite", "size": 19382},
      {
       "name": "render",
       "children": [
        {"name": "ArrowType", "size": 698},
        {"name": "EdgeRenderer", "size": 5569},
        {"name": "IRenderer", "size": 353},
        {"name": "ShapeRenderer", "size": 2247}
       ]
      },
      {"name": "ScaleBinding", "size": 11275},
      {"name": "Tree", "size": 7147},
      {"name": "TreeBuilder", "size": 9930}
     ]
    },
    {
     "name": "events",
     "children": [
      {"name": "DataEvent", "size": 2313},
      {"name": "SelectionEvent", "size": 1880},
      {"name": "TooltipEvent", "size": 1701},
      {"name": "VisualizationEvent", "size": 1117}
     ]
    },
    {
     "name": "legend",
     "children": [
      {"name": "Legend", "size": 20859},
      {"name": "LegendItem", "size": 4614},
      {"name": "LegendRange", "size": 10530}
     ]
    },
    {
     "name": "operator",
     "children": [
      {
       "name": "distortion",
       "children": [
        {"name": "BifocalDistortion", "size": 4461},
        {"name": "Distortion", "size": 6314},
        {"name": "FisheyeDistortion", "size": 3444}
       ]
      },
      {
       "name": "encoder",
       "children": [
        {"name": "ColorEncoder", "size": 3179},
        {"name": "Encoder", "size": 4060},
        {"name": "PropertyEncoder", "size": 4138},
        {"name": "ShapeEncoder", "size": 1690},
        {"name": "SizeEncoder", "size": 1830}
       ]
      },
      {
       "name": "filter",
       "children": [
        {"name": "FisheyeTreeFilter", "size": 5219},
        {"name": "GraphDistanceFilter", "size": 3165},
        {"name": "VisibilityFilter", "size": 3509}
       ]
      },
      {"name": "IOperator", "size": 1286},
      {
       "name": "label",
       "children": [
        {"name": "Labeler", "size": 9956},
        {"name": "RadialLabeler", "size": 3899},
        {"name": "StackedAreaLabeler", "size": 3202}
       ]
      },
      {
       "name": "layout",
       "children": [
        {"name": "AxisLayout", "size": 6725},
        {"name": "BundledEdgeRouter", "size": 3727},
        {"name": "CircleLayout", "size": 9317},
        {"name": "CirclePackingLayout", "size": 12003},
        {"name": "DendrogramLayout", "size": 4853},
        {"name": "ForceDirectedLayout", "size": 8411},
        {"name": "IcicleTreeLayout", "size": 4864},
        {"name": "IndentedTreeLayout", "size": 3174},
        {"name": "Layout", "size": 7881},
        {"name": "NodeLinkTreeLayout", "size": 12870},
        {"name": "PieLayout", "size": 2728},
        {"name": "RadialTreeLayout", "size": 12348},
        {"name": "RandomLayout", "size": 870},
        {"name": "StackedAreaLayout", "size": 9121},
        {"name": "TreeMapLayout", "size": 9191}
       ]
      },
      {"name": "Operator", "size": 2490},
      {"name": "OperatorList", "size": 5248},
      {"name": "OperatorSequence", "size": 4190},
      {"name": "OperatorSwitch", "size": 2581},
      {"name": "SortOperator", "size": 2023}
     ]
    },
    {"name": "Visualization", "size": 16540}
   ]
  }
 ]
}
```
{% endsimplemindmap %}


  • mindmup

指定连接形状 linkShape 生成 mindmup 版本的思维导图

{% simplemindmap type="mindmup",preset="default",linkShape="bracket" %}
```mindmup
{
  "title": "MindMapping",
  "id": 1,
  "formatVersion": 2,
  "ideas": {
    "11": {
      "title": "Software",
      "id": 8,
      "ideas": {
        "1": {
          "title": "FreeMind",
          "id": 9
        },
        "2": {
          "title": "XMind",
          "id": 10
        },
        "3": {
          "title": "MindMeister",
          "id": 11
        },
        "4": {
          "title": "iMindMap",
          "id": 13,
          "ideas": {
            "1": {
              "title": "by Tony Buzan",
              "id": 30
            }
          }
        },
        "5": {
          "title": "MindManager",
          "id": 14
        },
        "2.5": {
          "title": "MindMup",
          "id": 12
        }
      }
    },
    "21": {
      "title": "Misc",
      "id": 15,
      "ideas": {
        "1": {
          "title": "Visual Understanding Environment (VUE)",
          "id": 23,
          "ideas": {
            "1": {
              "title": "http://vue.tufts.edu/index.cfm",
              "id": 24
            }
          }
        },
        "2": {
          "title": "TiddlyMap",
          "id": 26
        },
        "3": {
          "title": "Orgmode.org",
          "id": 27
        },
        "4": {
          "title": "https://www.moh.io/mohiomap",
          "id": 31,
          "ideas": {}
        }
      }
    },
    "31": {
      "title": "Resources",
      "id": 2,
      "ideas": {
        "1": {
          "title": "http://lifehacker.com/five-best-mind-mapping-tools-476534555",
          "id": 18
        },
        "2": {
          "title": "http://lifehacker.com/5188833/hive-five-five-best-mind-mapping-applications",
          "id": 19
        },
        "3": {
          "title": "https://en.wikipedia.org/wiki/List_of_concept-_and_mind-mapping_software",
          "id": 21
        }
      },
      "attr": {
        "position": [
          67.5,
          255,
          1
        ],
        "style": {}
      }
    }
  }
}
```
{% endsimplemindmap %}


步骤＃3- 运行 gitbook 命令

  1. 运行 gitbook install .它将自动为您的 gitbook 安装 simple-mind-map 插件.

该步骤仅需要允许一次即可.

gitbook install

或者您可以运行 npm install gitbook-plugin-simple-mind-map 命令本地安装 gitbook-plugin-simple-mind-map 插件.

npm install gitbook-plugin-simple-mind-map
  1. 像往常一样构建您的书（ gitbook build ）或服务（ gitbook serve ）.
gitbook serve

示例

  • 官方文档配置文件

https://github.com/snowdreams1006/gitbook-plugin-simple-mind-map/blob/master/docs/book.json

{
    "plugins": ["simple-mind-map"],
    "pluginsConfig": {
        "simple-mind-map": {
            "type": "markdown",
            "preset": "colorful",
            "linkShape": "diagonal"
        }
    }
}
  • 官方示例配置文件

https://github.com/snowdreams1006/gitbook-plugin-simple-mind-map/blob/master/example/book.json

{
    "plugins": ["simple-mind-map"],
    "pluginsConfig": {
        "simple-mind-map": {
            "type": "markdown"
        }
    }
}
  • 示例 book.json 文件
{
    "plugins": ["simple-mind-map"]
}

或者,您可以添加 preset or linkShape and autoFit 作为默认设置选项:

{
    "plugins": ["simple-mind-map"],
    "pluginsConfig": {
        "simple-mind-map": {
            "type": "markdown",
            "preset": "colorful",
            "linkShape": "diagonal",
            "autoFit": true
        }
    }
}

或者您可以添加 style 以自定义思维导图样式：

{
    "plugins": ["simple-mind-map"],
    "pluginsConfig": {
        "simple-mind-map": {
            "type": "markdown",
            "preset": "colorful",
            "linkShape": "diagonal",
            "autoFit": true,
            "style": {
              "height":  "750px"
            }
        }
    }
}

注意 ：如果您的书还没有创建,以上代码段可以用作完整的 book.json 文件.

作者

👤 snowdreams1006

贡献

欢迎提供文稿，问题和功能请求！
随时检查问题页面 。

表示支持

如果这个项目对您有帮助，请给个星星 ！

版权

版权所有 ©2019 snowdreams1006 。

该项目是MIT许可的。

如果本文对你有所帮助,点赞评论和收藏那就再好不过了呢!

点击查看更多内容
发表于 2020.03.17 22:40， 共 7719 人浏览

本文原创发布于慕课网 ，转载请注明出处，谢谢合作

举报
1人点赞

若觉得本文不错，就分享一下吧！

评论

作者其他优质文章

正在加载中

雪之梦技术驿站

JAVA开发工程师
手记
篇
粉丝
3907
获赞与收藏
222

关注作者，订阅最新文章

相关文章推荐

阅读免费教程

感谢您的支持，我会继续努力的～
扫码打赏，你说多少就多少
赞赏金额会直接到老师账户
支付方式
打开微信扫一扫，即可进行扫码打赏哦
今天注册有机会得

100积分直接送

付费专栏免费学

大额优惠券免费领

立即参与 放弃机会
意见反馈 帮助中心 APP下载
官方微信

举报

0/150
提交
取消
