手把手教你在python中运行ansible-playbook

标签：

Python 运维工具

关于什么ansible，我这里就不做科普了，总之一句话，要做分布式系统的运维，实现批量系统配置、批量程序部署、批量运行命令等功能，ansible就是一大杀器，能令你事半功倍。

但作为一个cli工具，其使用场景还是受cli的限制，无法实现运行过程中更深入的交互和逻辑控制。ansible本身是用python做的，所以实际上是和python的脚本控制是无缝链接的，可以在python中直接使用。但怎奈关于这部分的内容，官网文档中本身就少得可怜，互联网上也少有关于这一块的介绍，所以这个博文试着抛砖引玉，为大家做个指引。

首先，我不是python大牛，没法直接从代码入手一行一行的去看整个ansible的架构和代码，并且官网上也说了，ansible的代码一直在重构（从网上找到的屈指可数的例子也证明了这一点，那些python里面调用ansible的例子，在新版本的ansbile中一个都跑不了），因此，我们需要的是一个思路： 从CLI开始入手

ansible playbook 的调用

我们以ansible-playbook为例子，说明一下怎么从CLI开始一步一步的找到方法在python中调用ansible

找到命令路径


$ which ansible-playbook

/Library/Frameworks/Python.framework/Versions/3.6/bin/ansible-playbook

找到源码并分析

通过以上命令找到ansible-playbook。打开文件(文件内容不用细看)：


#!/Library/Frameworks/Python.framework/Versions/3.6/bin/python3.6



# (c) 2012, Michael DeHaan <michael.dehaan@gmail.com>

#

# This file is part of Ansible

#

# Ansible is free software: you can redistribute it and/or modify

# it under the terms of the GNU General Public License as published by

# the Free Software Foundation, either version 3 of the License, or

# (at your option) any later version.

#

# Ansible is distributed in the hope that it will be useful,

# but WITHOUT ANY WARRANTY; without even the implied warranty of

# MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the

# GNU General Public License for more details.

#

# You should have received a copy of the GNU General Public License

# along with Ansible.  If not, see <http://www.gnu.org/licenses/>.



########################################################

from __future__ import (absolute_import, division, print_function)

__metaclass__ = type



__requires__ = ['ansible']





import os

import shutil

import sys

import traceback



from ansible import context

from ansible.errors import AnsibleError, AnsibleOptionsError, AnsibleParserError

from ansible.module_utils._text import to_text





# Used for determining if the system is running a new enough python version

# and should only restrict on our documented minimum versions

_PY3_MIN = sys.version_info[:2] >= (3, 5)

_PY2_MIN = (2, 6) <= sys.version_info[:2] < (3,)

_PY_MIN = _PY3_MIN or _PY2_MIN

if not _PY_MIN:

    raise SystemExit('ERROR: Ansible requires a minimum of Python2 version 2.6 or Python3 version 3.5. Current version: %s' % ''.join(sys.version.splitlines()))





class LastResort(object):

    # OUTPUT OF LAST RESORT

    def display(self, msg, log_only=None):

        print(msg, file=sys.stderr)



    def error(self, msg, wrap_text=None):

        print(msg, file=sys.stderr)





if __name__ == '__main__':



    display = LastResort()



    try:  # bad ANSIBLE_CONFIG or config options can force ugly stacktrace

        import ansible.constants as C

        from ansible.utils.display import Display

    except AnsibleOptionsError as e:

        display.error(to_text(e), wrap_text=False)

        sys.exit(5)



    cli = None

    me = os.path.basename(sys.argv[0])



    try:

        display = Display()

        display.debug("starting run")



        sub = None

        target = me.split('-')

        if target[-1][0].isdigit():

            # Remove any version or python version info as downstreams

            # sometimes add that

            target = target[:-1]



        if len(target) > 1:

            sub = target[1]

            myclass = "%sCLI" % sub.capitalize()

        elif target[0] == 'ansible':

            sub = 'adhoc'

            myclass = 'AdHocCLI'

        else:

            raise AnsibleError("Unknown Ansible alias: %s" % me)



        try:

            mycli = getattr(__import__("ansible.cli.%s" % sub, fromlist=[myclass]), myclass)

        except ImportError as e:

            # ImportError members have changed in py3

            if 'msg' in dir(e):

                msg = e.msg

            else:

                msg = e.message

            if msg.endswith(' %s' % sub):

                raise AnsibleError("Ansible sub-program not implemented: %s" % me)

            else:

                raise



        try:

            args = [to_text(a, errors='surrogate_or_strict') for a in sys.argv]

        except UnicodeError:

            display.error('Command line args are not in utf-8, unable to continue.  Ansible currently only understands utf-8')

            display.display(u"The full traceback was:\n\n%s" % to_text(traceback.format_exc()))

            exit_code = 6

        else:

            cli = mycli(args)

            exit_code = cli.run()



    except AnsibleOptionsError as e:

        cli.parser.print_help()

        display.error(to_text(e), wrap_text=False)

        exit_code = 5

    except AnsibleParserError as e:

        display.error(to_text(e), wrap_text=False)

        exit_code = 4

# TQM takes care of these, but leaving comment to reserve the exit codes

#    except AnsibleHostUnreachable as e:

#        display.error(str(e))

#        exit_code = 3

#    except AnsibleHostFailed as e:

#        display.error(str(e))

#        exit_code = 2

    except AnsibleError as e:

        display.error(to_text(e), wrap_text=False)

        exit_code = 1

    except KeyboardInterrupt:

        display.error("User interrupted execution")

        exit_code = 99

    except Exception as e:

        if C.DEFAULT_DEBUG:

            # Show raw stacktraces in debug mode, It also allow pdb to

            # enter post mortem mode.

            raise

        have_cli_options = bool(context.CLIARGS)

        display.error("Unexpected Exception, this is probably a bug: %s" % to_text(e), wrap_text=False)

        if not have_cli_options or have_cli_options and context.CLIARGS['verbosity'] > 2:

            log_only = False

            if hasattr(e, 'orig_exc'):

                display.vvv('\nexception type: %s' % to_text(type(e.orig_exc)))

                why = to_text(e.orig_exc)

                if to_text(e) != why:

                    display.vvv('\noriginal msg: %s' % why)

        else:

            display.display("to see the full traceback, use -vvv")

            log_only = True

        display.display(u"the full traceback was:\n\n%s" % to_text(traceback.format_exc()), log_only=log_only)

        exit_code = 250

    finally:

        # Remove ansible tmpdir

        shutil.rmtree(C.DEFAULT_LOCAL_TMP, True)



    sys.exit(exit_code)

可以看到，大部分的内容都是异常的处理，跳过不看，找出最重要的几句：


...

        if len(target) > 1:

            sub = target[1]

            myclass = "%sCLI" % sub.capitalize()

        elif target[0] == 'ansible':

            sub = 'adhoc'

            myclass = 'AdHocCLI'

        else:

            raise AnsibleError("Unknown Ansible alias: %s" % me)



        try:

            mycli = getattr(__import__("ansible.cli.%s" % sub, fromlist=[myclass]), myclass)

...

            cli = mycli(args)

            exit_code = cli.run()

通过这几行代码，我们可以定位到ansible.cli这个package的目录。下面支持多种CLI:


├── adhoc.py

├── arguments

│   ├── __init__.py

│   ├── __pycache__

│   │   ├── __init__.cpython-36.pyc

│   │   └── optparse_helpers.cpython-36.pyc

│   └── optparse_helpers.py

├── config.py

├── console.py

├── doc.py

├── galaxy.py

├── inventory.py

├── playbook.py

├── pull.py

└── vault.py

并且调用的方式也很简单，只需要搞清楚args是什么就可以了，你可以简单的加一句print(args)。

简化调用

最后以上代码可以简化为如下示例：


from ansible.cli.playbook import PlaybookCLI



mycli = PlaybookCLI



cli = mycli([" ",'-i', 'hosts.uat', 'kibana_deploy_plugin.yml'])

exit_code = cli.run()

注意，这里参数的方式['-i', 'hosts.uat', 'kibana_deploy_plugin.yml']，格式和我们平时运行ansible-playbook一样，只是需要以数组的方式提供。

运行一下，结果如下：


PLAY [Deploy kibana optimize] **************************************************



TASK [Gathering Facts] *********************************************************

fatal: [BI-LASS-Kibana_10.60.x.x]: UNREACHABLE! => {"changed": false, "msg": "Failed to connect to the host via ssh: ssh: connect to host 10.60.x.x port 22: Operation timed out", "unreachable": true}

fatal: [BI-LASS-Kibana_10.50.x.x]: UNREACHABLE! => {"changed": false, "msg": "Failed to connect to the host via ssh: ssh: connect to host 10.50.x.x port 22: Operation timed out", "unreachable": true}



PLAY RECAP *********************************************************************

BI-LASS-Kibana_10.60.x.x : ok=0    changed=0    unreachable=1    failed=0    skipped=0    rescued=0    ignored=0

BI-LASS-Kibana_10.50.x.x : ok=0    changed=0    unreachable=1    failed=0    skipped=0    rescued=0    ignored=0





Process finished with exit code 0

可见，脚本能正常运行，到这里，我们已经可以在python中调用ansible-playbook了。

调用后的交互

这还不够，我们需要交互，需要得到task运行的结果，并根据结果做额外的分析和逻辑处理，因此需要更深入的研究代码。

ansible的运行分析

cli.run()

先看看的cli.run()函数：


   def run(self):



        super(PlaybookCLI, self).run()



        # Note: slightly wrong, this is written so that implicit localhost

        # manages passwords

        sshpass = None

        becomepass = None

        passwords = {}



        # initial error check, to make sure all specified playbooks are accessible

        # before we start running anything through the playbook executor



        b_playbook_dirs = []

        for playbook in context.CLIARGS['args']:

            if not os.path.exists(playbook):

                raise AnsibleError("the playbook: %s could not be found" % playbook)

            if not (os.path.isfile(playbook) or stat.S_ISFIFO(os.stat(playbook).st_mode)):

                raise AnsibleError("the playbook: %s does not appear to be a file" % playbook)



            b_playbook_dir = os.path.dirname(os.path.abspath(to_bytes(playbook, errors='surrogate_or_strict')))

            # load plugins from all playbooks in case they add callbacks/inventory/etc

            add_all_plugin_dirs(b_playbook_dir)



            b_playbook_dirs.append(b_playbook_dir)



        set_collection_playbook_paths(b_playbook_dirs)



        # don't deal with privilege escalation or passwords when we don't need to

        if not (context.CLIARGS['listhosts'] or context.CLIARGS['listtasks'] or

                context.CLIARGS['listtags'] or context.CLIARGS['syntax']):

            (sshpass, becomepass) = self.ask_passwords()

            passwords = {'conn_pass': sshpass, 'become_pass': becomepass}



        # create base objects

        loader, inventory, variable_manager = self._play_prereqs()



        # (which is not returned in list_hosts()) is taken into account for

        # warning if inventory is empty.  But it can't be taken into account for

        # checking if limit doesn't match any hosts.  Instead we don't worry about

        # limit if only implicit localhost was in inventory to start with.

        #

        # Fix this when we rewrite inventory by making localhost a real host (and thus show up in list_hosts())

        CLI.get_host_list(inventory, context.CLIARGS['subset'])



        # flush fact cache if requested

        if context.CLIARGS['flush_cache']:

            self._flush_cache(inventory, variable_manager)



        # create the playbook executor, which manages running the plays via a task queue manager

        pbex = PlaybookExecutor(playbooks=context.CLIARGS['args'], inventory=inventory,

                                variable_manager=variable_manager, loader=loader,

                                passwords=passwords)



        results = pbex.run()



        if isinstance(results, list):

            for p in results:



                display.display('\nplaybook: %s' % p['playbook'])

                for idx, play in enumerate(p['plays']):

                    if play._included_path is not None:

                        loader.set_basedir(play._included_path)

                    else:

                        pb_dir = os.path.realpath(os.path.dirname(p['playbook']))

                        loader.set_basedir(pb_dir)



                    msg = "\n  play #%d (%s): %s" % (idx + 1, ','.join(play.hosts), play.name)

                    mytags = set(play.tags)

                    msg += '\tTAGS: [%s]' % (','.join(mytags))



                    if context.CLIARGS['listhosts']:

                        playhosts = set(inventory.get_hosts(play.hosts))

                        msg += "\n    pattern: %s\n    hosts (%d):" % (play.hosts, len(playhosts))

                        for host in playhosts:

                            msg += "\n      %s" % host



                    display.display(msg)



                    all_tags = set()

                    if context.CLIARGS['listtags'] or context.CLIARGS['listtasks']:

                        taskmsg = ''

                        if context.CLIARGS['listtasks']:

                            taskmsg = '    tasks:\n'



                        def _process_block(b):

                            taskmsg = ''

                            for task in b.block:

                                if isinstance(task, Block):

                                    taskmsg += _process_block(task)

                                else:

                                    if task.action == 'meta':

                                        continue



                                    all_tags.update(task.tags)

                                    if context.CLIARGS['listtasks']:

                                        cur_tags = list(mytags.union(set(task.tags)))

                                        cur_tags.sort()

                                        if task.name:

                                            taskmsg += "      %s" % task.get_name()

                                        else:

                                            taskmsg += "      %s" % task.action

                                        taskmsg += "\tTAGS: [%s]\n" % ', '.join(cur_tags)



                            return taskmsg



                        all_vars = variable_manager.get_vars(play=play)

                        for block in play.compile():

                            block = block.filter_tagged_tasks(all_vars)

                            if not block.has_tasks():

                                continue

                            taskmsg += _process_block(block)



                        if context.CLIARGS['listtags']:

                            cur_tags = list(mytags.union(all_tags))

                            cur_tags.sort()

                            taskmsg += "      TASK TAGS: [%s]\n" % ', '.join(cur_tags)



                        display.display(taskmsg)



            return 0

        else:

            return results

这个函数仍然很长，关键是：


# create the playbook executor, which manages running the plays via a task queue manager

pbex = PlaybookExecutor(playbooks=context.CLIARGS['args'], inventory=inventory,

                                variable_manager=variable_manager, loader=loader,

                                passwords=passwords)



        results = pbex.run()

这里用PlaybookExecutor对执行过程进行了封装，并且使用task queue manager。

PlaybookExecutor.run()

继续跟进PlaybookExecutor.run()，我们可以看到关键代码是：


class PlaybookExecutor:



    '''

    This is the primary class for executing playbooks, and thus the

    basis for bin/ansible-playbook operation.

    '''



    def __init__(self, playbooks, inventory, variable_manager, loader, passwords):

        self._playbooks = playbooks

        self._inventory = inventory

        self._variable_manager = variable_manager

        self._loader = loader

        self.passwords = passwords

        self._unreachable_hosts = dict()



        if context.CLIARGS.get('listhosts') or context.CLIARGS.get('listtasks') or \

                context.CLIARGS.get('listtags') or context.CLIARGS.get('syntax'):

            self._tqm = None

        else:

            self._tqm = TaskQueueManager(

                inventory=inventory,

                variable_manager=variable_manager,

                loader=loader,

                passwords=self.passwords,

                forks=context.CLIARGS.get('forks'),

            )

            ...

    def run(self):

        '''

        Run the given playbook, based on the settings in the play which

        may limit the runs to serialized groups, etc.

        '''

        ...

                    if self._tqm is None:

                        # we are just doing a listing

                        entry['plays'].append(play)



                    else:

                        self._tqm._unreachable_hosts.update(self._unreachable_hosts)



                        previously_failed = len(self._tqm._failed_hosts)

                        previously_unreachable = len(self._tqm._unreachable_hosts)



                        break_play = False

                        # we are actually running plays

                        batches = self._get_serialized_batches(play)

                        if len(batches) == 0:

                            self._tqm.send_callback('v2_playbook_on_play_start', play)

                            self._tqm.send_callback('v2_playbook_on_no_hosts_matched')

                        for batch in batches:

                            # restrict the inventory to the hosts in the serialized batch

                            self._inventory.restrict_to_hosts(batch)

                            # and run it...

                            result = self._tqm.run(play=play)

...

可以看到有几点：

如果参数包含listhosts、listtasks、listtags、syntax则不会真正运行，而是返回playbook的信息
如果需要运行，则通过TaskQueueManager，以forks的方式进行批量操作（这样的并发并非线程安全的）
我们需要进一步到_tqm.run(play=play)函数中进行观察

TaskQueueManager.run()

从以下代码可以看到几点：

ansible在TaskQueueManager才去遍历一个playbook下的roles和tasks
默认的strategy是linear strategy
当task在所有host上都执行完毕之后才会进入到下一个task


    def run(self, play):

        '''

        Iterates over the roles/tasks in a play, using the given (or default)

        strategy for queueing tasks. The default is the linear strategy, which

        operates like classic Ansible by keeping all hosts in lock-step with

        a given task (meaning no hosts move on to the next task until all hosts

        are done with the current task).

        '''



        if not self._callbacks_loaded:

            self.load_callbacks()



        all_vars = self._variable_manager.get_vars(play=play)

        warn_if_reserved(all_vars)

        templar = Templar(loader=self._loader, variables=all_vars)



        new_play = play.copy()

        new_play.post_validate(templar)

        new_play.handlers = new_play.compile_roles_handlers() + new_play.handlers



        self.hostvars = HostVars(

            inventory=self._inventory,

            variable_manager=self._variable_manager,

            loader=self._loader,

        )



        play_context = PlayContext(new_play, self.passwords, self._connection_lockfile.fileno())

        if (self._stdout_callback and

                hasattr(self._stdout_callback, 'set_play_context')):

            self._stdout_callback.set_play_context(play_context)



        for callback_plugin in self._callback_plugins:

            if hasattr(callback_plugin, 'set_play_context'):

                callback_plugin.set_play_context(play_context)



        self.send_callback('v2_playbook_on_play_start', new_play)



        # build the iterator

        iterator = PlayIterator(

            inventory=self._inventory,

            play=new_play,

            play_context=play_context,

            variable_manager=self._variable_manager,

            all_vars=all_vars,

            start_at_done=self._start_at_done,

        )



        # adjust to # of workers to configured forks or size of batch, whatever is lower

        self._initialize_processes(min(self._forks, iterator.batch_size))



        # load the specified strategy (or the default linear one)

        strategy = strategy_loader.get(new_play.strategy, self)

        if strategy is None:

            raise AnsibleError("Invalid play strategy specified: %s" % new_play.strategy, obj=play._ds)



        # Because the TQM may survive multiple play runs, we start by marking

        # any hosts as failed in the iterator here which may have been marked

        # as failed in previous runs. Then we clear the internal list of failed

        # hosts so we know what failed this round.

        for host_name in self._failed_hosts.keys():

            host = self._inventory.get_host(host_name)

            iterator.mark_host_failed(host)



        self.clear_failed_hosts()



        # during initialization, the PlayContext will clear the start_at_task

        # field to signal that a matching task was found, so check that here

        # and remember it so we don't try to skip tasks on future plays

        if context.CLIARGS.get('start_at_task') is not None and play_context.start_at_task is None:

            self._start_at_done = True



        # and run the play using the strategy and cleanup on way out

        play_return = strategy.run(iterator, play_context)



        # now re-save the hosts that failed from the iterator to our internal list

        for host_name in iterator.get_failed_hosts():

            self._failed_hosts[host_name] = True



        strategy.cleanup()

        self._cleanup_processes()

        return play_return

因此，我们仍然需要到strategy.run()一探究竟

strategy.run()

通过这部分代码


    def run(self, iterator, play_context):

        '''

        The linear strategy is simple - get the next task and queue

        it for all hosts, then wait for the queue to drain before

        moving on to the next task

        '''



        # iterate over each task, while there is one left to run

        result = self._tqm.RUN_OK

        work_to_do = True

        while work_to_do and not self._tqm._terminated:



            try:

                display.debug("getting the remaining hosts for this loop")

                hosts_left = self.get_hosts_left(iterator)

                display.debug("done getting the remaining hosts for this loop")



                # queue up this task for each host in the inventory

                callback_sent = False

                work_to_do = False



                host_results = []

                host_tasks = self._get_next_task_lockstep(hosts_left, iterator)



...



                    results += self._process_pending_results(iterator, max_passes=max(1, int(len(self._tqm._workers) * 0.1)))



...



        return super(StrategyModule, self).run(iterator, play_context, result)

(这个函数太长，我省略了大部分)

这里最终的一句就是results += self._process_pending_results(iterator, max_passes=max(1, int(len(self._tqm._workers) * 0.1)))，即我们是通过_process_pending_results函数进行处理的，并且在函数里面使用大量的回调：


                if task_result.is_failed() or task_result.is_unreachable():

                    self._tqm.send_callback('v2_runner_item_on_failed', task_result)

                elif task_result.is_skipped():

                    self._tqm.send_callback('v2_runner_item_on_skipped', task_result)

                else:

                    if 'diff' in task_result._result:

                        if self._diff or getattr(original_task, 'diff', False):

                            self._tqm.send_callback('v2_on_file_diff', task_result)

                    self._tqm.send_callback('v2_runner_item_on_ok', task_result)

这些回调来自于taskQueueManager

TaskQueueManager.send_callback()

从以下代码，我们可以看到这个回调可以来自于_stdout_callback


    def send_callback(self, method_name, *args, **kwargs):

        for callback_plugin in [self._stdout_callback] + self._callback_plugins:

            # a plugin that set self.disabled to True will not be called

            # see osx_say.py example for such a plugin

            if getattr(callback_plugin, 'disabled', False):

                continue



            # try to find v2 method, fallback to v1 method, ignore callback if no method found

            methods = []

            for possible in [method_name, 'v2_on_any']:

                gotit = getattr(callback_plugin, possible, None)

                if gotit is None:

                    gotit = getattr(callback_plugin, possible.replace('v2_', ''), None)

                if gotit is not None:

                    methods.append(gotit)

因此，只要我们能重写TaskQueueManager的stdout_callback，就可以获取中间结果

最终的代码

省略中间分析步骤，直接上代码




from ansible.cli.playbook import PlaybookCLI

from ansible.plugins.callback import CallbackBase

import json

from ansible.cli import CLI

from ansible.executor.playbook_executor import PlaybookExecutor

from ansible import context

from ansible import constants as C





class ResultCallback(CallbackBase):

    """A sample callback plugin used for performing an action as results come in



    If you want to collect all results into a single object for processing at

    the end of the execution, look into utilizing the ``json`` callback plugin

    or writing your own custom callback plugin

    """

    def v2_runner_on_ok(self, result, **kwargs):

        """Print a json representation of the result



        This method could store the result in an instance attribute for retrieval later

        """

        host = result._host

        print(json.dumps({host.name: result._result}, indent=4))





    def v2_runner_on_failed(self, result, **kwargs):

      host = result._host.get_name()

      self.runner_on_failed(host, result._result, False)

      print('===v2_runner_on_failed====host=%s===result=%s'%(host,result._result))



    def v2_runner_on_unreachable(self, result):

      host = result._host.get_name()

      self.runner_on_unreachable(host, result._result)

      print('===v2_runner_on_unreachable====host=%s===result=%s'%(host,result._result))



    def v2_runner_on_skipped(self, result):

        if C.DISPLAY_SKIPPED_HOSTS:

         host = result._host.get_name()

         self.runner_on_skipped(host, self._get_item(getattr(result._result,'results',{})))

         print("this task does not execute,please check parameter or condition.")



    def v2_playbook_on_stats(self, stats):

      print('===========play executes completed========')



cli = PlaybookCLI([" ",'-i', 'hosts.uat', 'kibana_deploy_plugin.yml'])



super(PlaybookCLI,cli).run()



loader, inventory, variable_manager = cli._play_prereqs()



CLI.get_host_list(inventory, context.CLIARGS['subset'])



pbex = PlaybookExecutor(playbooks=context.CLIARGS['args'], inventory=inventory,

                                variable_manager=variable_manager, loader=loader,

                                passwords=None)



pbex._tqm._stdout_callback = ResultCallback()

pbex.run()

运行一下，so nice…




===v2_runner_on_unreachable====host=BI-LASS-Kibana_10.60.x.x===result={'unreachable': True, 'msg': 'Failed to connect to the host via ssh: ssh: connect to host 10.60.x.x port 22: Operation timed out', 'changed': False}

===v2_runner_on_unreachable====host=BI-LASS-Kibana_10.60.x.x===result={'unreachable': True, 'msg': 'Failed to connect to the host via ssh: ssh: connect to host 10.60.x.x port 22: Operation timed out', 'changed': False}

===========play executes completed========

点击查看更多内容
