RadioButton 切换按钮 做类似QQ 消息与电话

01

02

03

04

05

06

07

08

09

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"

    xmlns:tools="http://schemas.android.com/tools"

    android:layout_width="match_parent"

    android:layout_height="match_parent"

    android:background="#DCDCDC"

    android:orientation="vertical">

    <RelativeLayout

        android:id="@+id/rl"

        android:layout_width="match_parent"

        android:layout_height="45dp"

        android:layout_marginBottom="10dp"

        android:layout_marginTop="10dp">

        <RadioGroup

            android:id="@+id/select"

            android:layout_width="200dp"

            android:layout_height="match_parent"

            android:layout_centerInParent="true"

            android:orientation="horizontal">

            <RadioButton

                android:id="@+id/dialUp"

                android:layout_width="match_parent"

                android:layout_height="match_parent"

                android:layout_gravity="center_vertical"

                android:layout_weight="1"

                android:background="@drawable/radiobutton_left_bg"

                android:button="@null"

                android:checked="true"

                android:gravity="center"

                android:text="拨号"

                android:textColor="@drawable/text_select" />

            <RadioButton

                android:id="@+id/contacts"

                android:layout_width="match_parent"

                android:layout_height="match_parent"

                android:layout_gravity="center_vertical"

                android:layout_weight="1"

                android:background="@drawable/radiobutton_right_bg"

                android:button="@null"

                android:gravity="center"

                android:text="联系人"

                android:textColor="@drawable/text_select" />

        </RadioGroup>

    </RelativeLayout>

    <View

        android:id="@+id/view"

        android:layout_width="match_parent"

        android:layout_height="2px"

        android:layout_below="@+id/rl"

        android:background="#D3D3D3" />

    <FrameLayout

        android:id="@+id/franme_meun"

        android:layout_width="match_parent"

        android:layout_height="match_parent"

        android:layout_below="@+id/view"

        android:background="#FFFFFF" />

</RelativeLayout>

01

02

03

04

05

06

07

08

09

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

public class HomeActivity   extends AppCompatActivity   {

    private RadioGroup mSelect;

    //拨号

    private RadioButton mDialUp;

    //联系人

    private RadioButton mContacts;

    @Override

    protected void onCreate(Bundle savedInstanceState) {

        super.onCreate(savedInstanceState);

        setContentView(R.layout.activity_home);

        findView();

    }

    private void findView() {

        mDialUp   = (RadioButton) findViewById(R.id.dialUp);

        mContacts   = (RadioButton) findViewById(R.id.contacts);

        mSelect   = (RadioGroup) findViewById(R.id.select);

        mSelect.setOnCheckedChangeListener(listener);

        //   设置默认显示页面

        Fragment   dialUp = new DialUpFragment();

        FragmentManager   fmangerhp = getFragmentManager();

        FragmentTransaction   ftranhp = fmangerhp.beginTransaction();

        ftranhp.replace(R.id.franme_meun,   dialUp);

        ftranhp.commit();

    }

    private RadioGroup.OnCheckedChangeListener   listener = new RadioGroup.OnCheckedChangeListener()   {

        @Override

        public void onCheckedChanged(RadioGroup group, int checkedId) {

            //   TODO Auto-generated method stub

            switch (checkedId) {

                case R.id.dialUp:

                    //   这里是你想要跳转的界面

                    Fragment   dialUp = new DialUpFragment();

                    FragmentManager   fmangerhp = getFragmentManager();

                    FragmentTransaction   ftranhp = fmangerhp.beginTransaction();

                    ftranhp.replace(R.id.franme_meun,   dialUp);

                    ftranhp.commit();

                    mDialUp.setChecked(true);

                    break;

                case R.id.contacts:

                    //   这里是你想要跳转的界面

                    Fragment   contacts = new ContactsFragment();

                    FragmentManager   sanManager = getFragmentManager();

                    FragmentTransaction   sanfTransaction = sanManager.beginTransaction();

                    sanfTransaction.replace(R.id.franme_meun,   contacts);

                    sanfTransaction.commit();

                    break;

                default:

                    break;

            }

        }

    };

}
