仿MIUI8挂断电话动画

1

compile   'com.android.support:cardview-v7:24.1.1'

01

02

03

04

05

06

07

08

09

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

<android.support.v7.widget.CardView

       android:id="@+id/cardview_1"

       android:layout_width="match_parent"

       android:layout_height="match_parent"

       app:cardElevation="10dp">

       <RelativeLayout

           android:layout_width="match_parent"

           android:layout_height="match_parent">

           <ImageView

               android:id="@+id/iv_img"

               android:layout_width="100dp"

               android:layout_height="100dp"

               android:layout_centerHorizontal="true"

               android:layout_marginTop="50dp" />

           <Button

               android:id="@+id/btn_start"

               android:layout_width="wrap_content"

               android:layout_height="wrap_content"

               android:layout_alignParentBottom="true"

               android:layout_centerHorizontal="true"

               android:layout_marginBottom="50dp"

               android:text="开始" />

       </RelativeLayout>

   </android.support.v7.widget.CardView>

1

2

3

4

cardview_1 = (CardView)   findViewById(R.id.cardview_1);

cardview_1.setBackgroundColor(Color.BLACK);

       //设置波浪颜色

cardview_1.setCardBackgroundColor(Color.parseColor("#000000"));

01

02

03

04

05

06

07

08

09

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

private void startAnimation(View   view) {

        //置回初始状态

        cardview_1.setCardBackgroundColor(Color.parseColor("#000000"));

        cardview_1.setBackgroundColor(Color.BLACK);

        //因为CircularReveal动画是api21之后才有的,所以加个判断语句,免得崩溃

        if (Build.VERSION.SDK_INT >=   Build.VERSION_CODES.LOLLIPOP) {

            int cicular_R = view.getHeight() / 2 > view.getWidth() / 2 ? view.getHeight() : view.getWidth();

            //   一个整型数组，用来存储按钮的在屏幕的X、Y坐标

            int[]   start_location = new int[2];

            //   这是获取购买按钮的在屏幕的X、Y坐标（这也是动画开始的坐标）

            iv_img.getLocationInWindow(start_location);

            int width = iv_img.getWidth();

            int height = iv_img.getHeight();

            //   view 操作的视图

            //   centerX 动画开始的中心点X

            //   centerY 动画开始的中心点Y

            //   startRadius 动画开始半径

            //   startRadius 动画结束半径

            Animator   animator = ViewAnimationUtils.createCircularReveal(cardview_1,

                    start_location[0]   + width / 2, start_location[1] + height / 2, cicular_R, width);

            animator.setInterpolator(new LinearInterpolator());

            animator.setDuration(300);

            animator.addListener(new Animator.AnimatorListener() {

                @Override

                public void onAnimationStart(Animator animation) {

                }

                @Override

                public void onAnimationEnd(Animator animation) {

                    cardview_1.setBackgroundColor(Color.WHITE);

                    //移除屏幕

                    removeWindow();

                }

                @Override

                public void onAnimationCancel(Animator animation) {

                }

                @Override

                public void onAnimationRepeat(Animator animation) {

                }

            });

            animator.start();

        }   else {

            Toast.makeText(this,   "SDK版本太低,请升级", Toast.LENGTH_SHORT).show();

        }

    }

01

02

03

04

05

06

07

08

09

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

private void removeWindow()   {

        int[]   start_location = new int[2];

        //   这是获取购买按钮的在屏幕的X、Y坐标（这也是动画开始的坐标）

        iv_img.getLocationInWindow(start_location);

        int starty = start_location[1] +   iv_img.getHeight();

        TranslateAnimation   animation = new TranslateAnimation(0,   0, start_location[1] - iv_img.getHeight() / 2, -starty);

        animation.setDuration(200);

        animation.setAnimationListener(new Animation.AnimationListener() {

            @Override

            public void onAnimationStart(Animation animation) {

            }

            @Override

            public void onAnimationEnd(Animation animation) {

                cardview_1.setVisibility(View.GONE);

                btn_again.setVisibility(View.VISIBLE);

            }

            @Override

            public void onAnimationRepeat(Animation animation) {

            }

        });

        iv_img.startAnimation(animation);

    }
