arcgis api for js入门开发系列四地图查询(含源代码)

标签：
Html/CSS JQuery JavaScript

备注：由于实现本篇功能的需求，修改了地图数据的dlsearch.mxd，然后更新了地图服务，需要的在文章最后有提供最新的mxd以及源代码下载的
上一篇实现了demo的地图工具栏，本篇新增地图查询功能，包括属性查询和空间查询两大块，截图如下：
属性查询效果图：
图片描述
图片描述
空间查询效果图：
图片描述
谈核心代码实现之前，我大概的讲一讲arcgis for js的地图查询方式，一般来说，总共有三种查询方式：FindTask、IdentifyTask、QueryTask
（1）FindTask查询模式：基于关键字来模糊查询地图图层，属于文本型的，不能基于地图的设置的空间范围Geometry来查询，但是可以跨越多个图层来查询，比如餐饮图层、医疗服务图层等等；
（2）IdentifyTask查询模式：跟FindTask反过来，基于地图的设置的空间范围Geometry来查询，不能基于文本查询，同样可以跨越多个图层来查询；
（3）QueryTask查询模式：结合FindTask以及IdentifyTask一体，可以基于文本或者空间范围来查询，但是限定了查询图层，不能跨越多个图层来查询；
下面依据属性查询和空间查询不同思路来讲解一下核心实现模块，实现之前在map.js必须引入相关的调用api包：

(function () {
    dojo.require("esri.tasks.FindTask");
    dojo.require("esri.tasks.FindParameters");
    dojo.require("esri.tasks.IdentifyTask");
    dojo.require("esri.tasks.IdentifyParameters");
})();

一、属性查询模块：
图片描述
1是基于FindTask属性查询的，可以查询的图层覆盖：餐饮、住宿、金融服务、购物、科研教育、医疗服务;
2是基于QueryTask属性查询，分类查询；
FindTask属性查询实现核心代码：

var find = new esri.tasks.FindTask(MapConfig.vecMapUrl + "/");//URL
                var params = new esri.tasks.FindParameters();
                params.layerIds = [0,1,2,3,4,5]; //设置查询图层列表
                params.searchFields = ["NAME"]; //设置查询图层的字段,根据NAME字段来模糊查询
                params.searchText = keyword;//设置模糊查询的关键词
                params.returnGeometry = true;//返回空间查询的geometry，方便把返回值结果以图标形式叠加在地图上
                find.execute(params, DCI.Poi.findInfo);
/**
     * 所有图层的属性查询结果--FindTask
    */
    findInfo: function (results) {
        DCI.Poi.clearAndhide();
        var sms = new esri.symbol.PictureMarkerSymbol(getRootPath() + "Content/images/plot/point1.png", 11, 13);
        var innerStr = [];

        var featureCount = results.length;
        //最大的显示页面
        var maxpage = Math.ceil(featureCount / DCI.Poi.pageSize);
        if (results.length > 0) {
            $("#listpages").css({ display: "block" });
            for (var i = 0; i < DCI.Poi.pageSize; i++) {
                var rExtent = null;
                var iId = i + 1;
                var baseGraphicsymbol = new esri.symbol.PictureMarkerSymbol(getRootPath() + "Content/images/poi/dw" + iId + ".png", 25, 25);
                var infactItem = DCI.Poi.pageIndex * DCI.Poi.pageSize + i;
                var tempID = "tempID" + i;
                var pId = "poi_" + iId;
                if (results[infactItem] == undefined) //最后一页没有记录了 跳出循环
                    break;

                var attr = { "title": results[infactItem].feature.attributes.NAME, "content": results[infactItem].feature.attributes.NAME };
                var baseGraphic = new esri.Graphic(results[infactItem].feature.geometry, baseGraphicsymbol, attr);
                baseGraphic.id = tempID;
                DCI.Poi.graphicslayer.add(baseGraphic);

                innerStr.push('<div class="left_list_li_box" onmouseover="DCI.Poi.onPOIMouseOverRecord(' + i + ',\'' + tempID + '\')" onmouseout="DCI.Poi.onPOIMouseOutRecord(' + i + ',\'' + tempID + '\')"  id="' + pId + '">');
                innerStr.push('<div class="left_list_li_box_top">');
                innerStr.push('<div class="left2_box2">');
                innerStr.push('<div class="left_list_li1">');
                innerStr.push('<p>');
                innerStr.push('<a onclick="DCI.Poi.toLocationPOI(' + i + ',\'' + tempID + '\',\'' + results[infactItem].feature.attributes.NAME + '\')">' + results[infactItem].feature.attributes.NAME + '</a><br/>');
                innerStr.push('</p>');
                innerStr.push('</div>');
                innerStr.push('</div>')
                innerStr.push('</div>');
                innerStr.push('</div>');
            }
            $("#showLists").html(innerStr.join(''));

            //设置地图显示范围
            if (rExtent == null)
                rExtent = baseGraphic._extent;
            else {
                rExtent = rExtent.union(baseGraphic._extent);
            }

            DCI.Poi.map.setExtent(rExtent.expand(2));
            DCI.Poi.map.resize();
            DCI.Poi.map.reposition();
            //分页工具条
            $("#listpages").PageOperator({
                containerID: "listpages",
                count: featureCount,
                pageIndex: DCI.Poi.pageIndex,
                maxPage: maxpage,
                callback: function (pageIndex) {
                    var keyword = $("#skeyword").val();
                    DCI.Poi.pageIndex = pageIndex;
                    DCI.Poi.search(keyword, pageIndex, DCI.Poi.pageSize);
                }
            });
        } else {
            alert("搜索不到相关数据");
        }
    }

QueryTask属性查询实现核心代码：

var query = new esri.tasks.Query();
query.returnGeometry = true;
query.outFields = ["NAME"];
query.where = "1=1";
queryTask = new esri.tasks.QueryTask(typeUrl);
queryTask.execute(query, DCI.Poi.navInfo);
/**
     * 指定图层的属性查询--Query
    */
    navInfo: function (results) {
        DCI.Poi.clearAndhide();
        var sms = new esri.symbol.PictureMarkerSymbol(getRootPath() + "Content/images/plot/point1.png", 11, 13);
        var innerStr = [];

        var featureCount = results.features.length;
        //最大的显示页面
        var maxpage = Math.ceil(featureCount / DCI.Poi.pageSize);
        if (results.features.length > 0) {
            $("#listpages").css({ display: "block" });
            for (var i = 0; i < DCI.Poi.pageSize; i++) {
                var rExtent = null;
                var iId = i + 1;
                var baseGraphicsymbol = new esri.symbol.PictureMarkerSymbol(getRootPath() + "Content/images/poi/dw" + iId + ".png", 25, 25);
                var infactItem = DCI.Poi.pageIndex * DCI.Poi.pageSize + i;
                var tempID = "tempID" + i;
                var pId = "poi_" + iId;
                if (results.features[infactItem] == undefined) //最后一页没有记录了 跳出循环
                    break;

                var attr = { "title": results.features[i].attributes.NAME, "content": results.features[i].attributes.NAME };
                var baseGraphic = new esri.Graphic(results.features[infactItem].geometry, baseGraphicsymbol, attr);
                baseGraphic.id = tempID;
                DCI.Poi.graphicslayer.add(baseGraphic);

                innerStr.push('<div class="left_list_li_box" onmouseover="DCI.Poi.onPOIMouseOverRecord(' + i + ',\'' + tempID + '\')" onmouseout="DCI.Poi.onPOIMouseOutRecord(' + i + ',\'' + tempID + '\')"  id="' + pId + '">');
                innerStr.push('<div class="left_list_li_box_top">');
                innerStr.push('<div class="left2_box2">');
                innerStr.push('<div class="left_list_li1">');
                innerStr.push('<p>');
                innerStr.push('<a onclick="DCI.Poi.toLocationPOI(' + i + ',\'' + tempID + '\',\'' + results.features[infactItem].attributes.NAME + '\')">' + results.features[infactItem].attributes.NAME + '</a><br/>');
                innerStr.push('</p>');
                innerStr.push('</div>');
                innerStr.push('</div>')
                innerStr.push('</div>');
                innerStr.push('</div>');
            }
            $("#showLists").html(innerStr.join(''));

            //设置地图显示范围
            if (rExtent == null)
                rExtent = baseGraphic._extent;
            else {
                rExtent = rExtent.union(baseGraphic._extent);
            }

            DCI.Poi.map.setExtent(rExtent.expand(2));
            DCI.Poi.map.resize();
            DCI.Poi.map.reposition();
            //分页工具条
            $("#listpages").PageOperator({
                containerID: "listpages",
                count: featureCount,
                pageIndex: DCI.Poi.pageIndex,
                maxPage: maxpage,
                callback: function (pageIndex) {
                    var keyword = $("#skeyword").val();
                    DCI.Poi.pageIndex = pageIndex;
                    DCI.Poi.search(keyword, pageIndex, DCI.Poi.pageSize);
                }
            });
        } else {
            alert("搜索不到相关数据");
        }
    }

二、空间查询模块：
图片描述
1是基于QueryTask空间查询，查询指定的餐饮图层;
2是基于IdentifyTask空间查询，可以查询的图层覆盖：餐饮、住宿、金融服务、购物、科研教育、医疗服务；
IdentifyTask空间查询实现核心代码：

/**
     * 所有图层的空间查询--Identify
    */
    searchIdentify: function (geometry) {
        var identifyTask = new esri.tasks.IdentifyTask(DCI.SpatialQuery.spatialQuery.layerName);//URL
        var identifyParams = new esri.tasks.IdentifyParameters();
        identifyParams.tolerance = 3;//设置绘制框选图形范围的屏幕像素距离，这个值必须要设置，不然查询不到，我用官网在线例子的默认3
        identifyParams.returnGeometry = true;//返回空间查询的geometry，方便把返回值结果以图标形式叠加在地图上
        identifyParams.layerIds = [0, 1, 2, 3, 4, 5];//设置查询图层列表
        identifyParams.layerOption = esri.tasks.IdentifyParameters.LAYER_OPTION_ALL;//设置查询的模式，我设置了可以查询所有的图层，不管是否可见，其他的模式具体参照api:https://developers.arcgis.com/javascript/3/jsapi/identifyparameters-amd.html
        identifyParams.geometry = geometry;//设置绘制框选图形范围
        identifyParams.mapExtent = DCI.SpatialQuery.map.extent;//设置查询的地图当前范围，也是必须设置的
        identifyTask.execute(identifyParams, DCI.SpatialQuery.identifyInfo);
    },
/**
     * 所有图层的空间查询获取结果--Identify
    */
    identifyInfo: function (results) {
        //清空graphiclayer
        DCI.SpatialQuery.graphicslayer.clear();
        DCI.SpatialQuery.map.infoWindow.hide();
        var sms = new esri.symbol.PictureMarkerSymbol(getRootPath() + "Content/images/plot/point1.png", 11, 13);
        var innerStr = [];
        var featureCount = results.length;
        if (results == null || featureCount == 0) {
            DCI.Poi.addSearchErrorPage("queryshowList");
            $("#querylistpage").css({ display: "none" });
            return;
        }
        //最大的显示页面
        var maxpage = Math.ceil(featureCount / DCI.SpatialQuery.pageSize);
        $("#querylistpage").css({ display: "block" });
        if (results.length > 0) {
            for (var i = 0; i < DCI.SpatialQuery.pageSize; i++) {
                var rExtent = null;
                var iId = i + 1;
                var baseGraphicsymbol = new esri.symbol.PictureMarkerSymbol(getRootPath() + "Content/images/poi/dw" + iId + ".png", 25, 25);
                var infactItem = DCI.SpatialQuery.pageIndex * DCI.SpatialQuery.pageSize + i;
                var tempID = "tempID" + i;
                var pId = "poi_" + iId;
                if (results[infactItem] == undefined) //最后一页没有记录了 跳出循环
                    break;
                var attr = { "title": results[infactItem].feature.attributes.NAME, "content": results[infactItem].feature.attributes.NAME };
                var baseGraphic = new esri.Graphic(results[infactItem].feature.geometry, baseGraphicsymbol, attr);
                baseGraphic.id = tempID;
                DCI.SpatialQuery.graphicslayer.add(baseGraphic);
                innerStr.push('<div class="left_list_li_box" onmouseover="DCI.SpatialQuery.onPOIMouseOverRecord(' + i + ',\'' + tempID + '\')" onmouseout="DCI.SpatialQuery.onPOIMouseOutRecord(' + i + ',\'' + tempID + '\')"  id="' + pId + '">');
                innerStr.push('<div class="left_list_li_box_top">');
                innerStr.push('<div class="left2_box2">');
                innerStr.push('<div class="left_list_li1">');
                innerStr.push('<p>');
                innerStr.push('<a onclick="DCI.SpatialQuery.toLocation(' + i + ',\'' + tempID + '\',\'' + results[infactItem].feature.attributes.NAME + '\')">' + results[infactItem].feature.attributes.NAME + '</a><br/>');
                innerStr.push('</p>');
                innerStr.push('</div>');
                innerStr.push('</div>')
                innerStr.push('</div>');
                innerStr.push('</div>');
            }
            $("#queryshowList").html(innerStr.join(''));

            //设置地图显示范围
            if (rExtent == null)
                rExtent = baseGraphic._extent;
            else {
                rExtent = rExtent.union(baseGraphic._extent);
            }

            DCI.SpatialQuery.map.setExtent(rExtent.expand(2));
            DCI.SpatialQuery.map.resize();
            DCI.SpatialQuery.map.reposition();
            //分页工具条
            $("#querylistpage").PageOperator({
                containerID: "querylistpage",
                count: featureCount,
                pageIndex: DCI.SpatialQuery.pageIndex,
                maxPage: maxpage,
                callback: function (pageIndex) {
                    DCI.SpatialQuery.pageIndex = pageIndex;
                    if (DCI.SpatialQuery.type[0] == "0") {//指定图层的空间查询
                        DCI.SpatialQuery.searchSP(DCI.SpatialQuery.sgeometry);
                    } else if (DCI.SpatialQuery.type[0] == "1") {//所有图层的空间查询
                        DCI.SpatialQuery.searchIdentify(DCI.SpatialQuery.sgeometry);
                    }
                }
            });
        } else {
            alert("搜索不到相关数据");
        }
    },

QueryTask空间查询实现核心代码：

/**
     * 指定图层的空间查询--Query
    */
    searchSP: function (geometry) {
        var queryTask = new esri.tasks.QueryTask(DCI.SpatialQuery.spatialQuery.layerName);//URL
        var query = new esri.tasks.Query();
        query.returnGeometry = true;//返回空间查询的geometry，方便把返回值结果以图标形式叠加在地图上
        query.outFields = [DCI.SpatialQuery.spatialQuery.returnFields];//设置返回值的字段
        query.geometry = geometry;//设置绘制框选图形范围
        queryTask.execute(query, DCI.SpatialQuery.navInfo);
    },
    /**
     * 所有图层的空间查询--Query
    */
    navInfo: function (results) {
        //清空graphiclayer
        DCI.SpatialQuery.graphicslayer.clear();
        DCI.SpatialQuery.map.infoWindow.hide();
        var sms = new esri.symbol.PictureMarkerSymbol(getRootPath() + "Content/images/plot/point1.png", 11, 13);
        var innerStr = [];
        var featureCount = results.features.length;
        if (results.features == null || featureCount == 0) {
            DCI.Poi.addSearchErrorPage("queryshowList");
            $("#querylistpage").css({ display: "none" });
            return;
        }
        //最大的显示页面
        var maxpage = Math.ceil(featureCount / DCI.SpatialQuery.pageSize);
        $("#querylistpage").css({ display: "block" });
        if (results.features.length > 0) {
            for (var i = 0; i < DCI.SpatialQuery.pageSize; i++) {
                var rExtent = null;
                var iId = i + 1;
                var baseGraphicsymbol = new esri.symbol.PictureMarkerSymbol(getRootPath() + "Content/images/poi/dw" + iId + ".png", 25, 25);
                var infactItem = DCI.SpatialQuery.pageIndex * DCI.SpatialQuery.pageSize + i;
                var tempID = "tempID" + i;
                var pId = "poi_" + iId;
                if (results.features[infactItem] == undefined) //最后一页没有记录了 跳出循环
                    break;
                var attr = { "title": results.features[i].attributes.NAME, "content": results.features[i].attributes.NAME };
                var baseGraphic = new esri.Graphic(results.features[infactItem].geometry, baseGraphicsymbol, attr);
                baseGraphic.id = tempID;
                DCI.SpatialQuery.graphicslayer.add(baseGraphic);
                innerStr.push('<div class="left_list_li_box" onmouseover="DCI.SpatialQuery.onPOIMouseOverRecord(' + i + ',\'' + tempID + '\')" onmouseout="DCI.SpatialQuery.onPOIMouseOutRecord(' + i + ',\'' + tempID + '\')"  id="' + pId + '">');
                innerStr.push('<div class="left_list_li_box_top">');
                innerStr.push('<div class="left2_box2">');
                innerStr.push('<div class="left_list_li1">');
                innerStr.push('<p>');
                innerStr.push('<a onclick="DCI.SpatialQuery.toLocation(' + i + ',\'' + tempID + '\',\'' + results.features[infactItem].attributes.NAME + '\')">' + results.features[infactItem].attributes.NAME + '</a><br/>');
                innerStr.push('</p>');
                innerStr.push('</div>');
                innerStr.push('</div>')
                innerStr.push('</div>');
                innerStr.push('</div>');
            }
            $("#queryshowList").html(innerStr.join(''));

            //设置地图显示范围
            if (rExtent == null)
                rExtent = baseGraphic._extent;
            else {
                rExtent = rExtent.union(baseGraphic._extent);
            }

            DCI.SpatialQuery.map.setExtent(rExtent.expand(2));
            DCI.SpatialQuery.map.resize();
            DCI.SpatialQuery.map.reposition();
            //分页工具条
            $("#querylistpage").PageOperator({
                containerID: "querylistpage",
                count: featureCount,
                pageIndex: DCI.SpatialQuery.pageIndex,
                maxPage: maxpage,
                callback: function (pageIndex) {
                    DCI.SpatialQuery.pageIndex = pageIndex;
                    if (DCI.SpatialQuery.type[0] == "0") {//指定图层的空间查询
                        DCI.SpatialQuery.searchSP(DCI.SpatialQuery.sgeometry);
                    } else if (DCI.SpatialQuery.type[0] == "1") {//所有图层的空间查询
                        DCI.SpatialQuery.searchIdentify(DCI.SpatialQuery.sgeometry);
                    }
                }
            });
        } else {
            alert("搜索不到相关数据");
        }
    }

最后，提供源代码下载：http://pan.baidu.com/s/1eRCoH02
dlsearch.mxd下载：http://pan.baidu.com/s/1qYRJGKG

点击查看更多内容
发表于 2016.11.17 22:01， 共 5305 人浏览

本文原创发布于慕课网 ，转载请注明出处，谢谢合作

举报
4人点赞

若觉得本文不错，就分享一下吧！

评论

作者其他优质文章

正在加载中

GIS之家

Web前端工程师
手记
篇
粉丝
141
获赞与收藏
297

关注作者，订阅最新文章

相关文章推荐

阅读免费教程

感谢您的支持，我会继续努力的～
扫码打赏，你说多少就多少
赞赏金额会直接到老师账户
支付方式
打开微信扫一扫，即可进行扫码打赏哦
今天注册有机会得

100积分直接送

付费专栏免费学

大额优惠券免费领

立即参与 放弃机会
意见反馈 帮助中心 APP下载
官方微信

举报

0/150
提交
取消
